Bug #111732

【Figure】【EVT】【电气性能】E01 辅助启动过电压：试验中，有未知元器件击穿，风扇不转，有烧焦味，WiFi，蓝牙，视频和以太网功能失效， 试验后，重新上电操作，WiFi，蓝牙，视频和以太网功能正常。

Added by 项目二组_SD3 曾小文 almost 3 years ago. Updated over 2 years ago.

Status:CLOSEDStart date:2022-09-05
Priority:HighDue date:
Assignee:项目二组_SD3 曾小文% Done:

100%

Category:BSP
Target version:依赖硬件的bugList
Need_Info:-- Found Version:2022.08.25
Resolution:FIXED Degrated:No
Severity:Major Verified Version:
Reproducibility:Every time Fixed Version:
Test Type:Release Test Root cause:由于MCU软件代码存在的问题，目前已经修复

Description

E01 辅助启动过电压：有未知元器件击穿,风扇不转，有烧焦味道。


FigureApp.mot (77.5 KB) CD BSP-陈杰, 2022-09-26 16:00

FigureV0.0.1.20221013.1.mot (299 KB) CD BSP-陈杰, 2022-10-18 10:21

20220916-154513

History

#1 Updated by SZ-硬件二组_SD3 王苗 almost 3 years ago

  • Status changed from New to ASSIGNED
  • Assignee changed from SZ-硬件二组_SD3 王苗 to 项目二组_SD3 曾小文

实验室风扇12v,供电，耐压不够28V,实验时候电压会到28V，风扇烧坏。解决方案：选用5V风扇，5V电源前级用LDO电源转5V供电给到风扇。目前在EVT2的板子上已经导入，待验证。

#2 Updated by CD TPM-申艳艳 almost 3 years ago

  • Category set to EE

#3 Updated by SZ HW Test-曾小文 almost 3 years ago

  • Subject changed from 【Figure】【EVT】【电气性能】E01 辅助启动过电压：有未知元器件击穿,风扇不转，有烧焦味道。 to 【Figure】【EVT】【电气性能】E01 辅助启动过电压：试验中，有未知元器件击穿，风扇不转，有烧焦味，WiFi，蓝牙，视频和以太网功能失效， 试验后，重新上电操作，WiFi，蓝牙，视频和以太网功能正常。
  • Category changed from EE to BSP
  • Assignee changed from 项目二组_SD3 曾小文 to CD BSP-唐金泽

烧焦味道硬件确认为风扇烧坏，后续更换5V风扇。
功能失效问题需要软件DEBUG

#4 Updated by CD BSP-唐金泽 almost 3 years ago

  • Assignee changed from CD BSP-唐金泽 to SZ HW Test-曾小文

“功能失效问题需要软件DEBUG”，从描述看是电压过高，击穿硬件导致损坏
需要软件怎么样配合？

#5 Updated by CD BSP-唐金泽 almost 3 years ago

陈杰，请针对CLASS逻辑，先进行添加，风扇后续会进行调整

#6 Updated by CD BSP-陈杰 almost 3 years ago

目前风扇得控制策略已经提交入库，本地软测已经验证ok。过压保护功能已经开发，目前只是满足classA和classC得部分功能。classC得记忆功能AF还在开发。等待开发完成后，还需要进行联合调试。

#7 Updated by 物联网项目组-RD3_CDTS 周飞 almost 3 years ago

  • Target version set to 依赖硬件的bugList

#8 Updated by CD BSP-陈杰 over 2 years ago

  • File FigureV0.0.1.20221013.1.mot added
  • Status changed from ASSIGNED to RESOLVED
  • Assignee changed from CD BSP-陈杰 to 项目二组_SD3 曾小文
  • % Done changed from 80 to 100
  • Resolution changed from -- to FIXED
  • Degrated changed from -- to No
  • Root cause set to 由于MCU软件代码存在的问题，目前已经修复

MCU使用的文件为：
FigureV0.0.1.20221013.1.mot
SOC版本：
可以使用最新版本进行测试。

#9 Updated by SZ HW Test-曾小文 over 2 years ago

  • Status changed from RESOLVED to VERIFIED

12V风扇改成5V风扇，增加记忆功能后，王苗在中认联实验室复测PASS

#10 Updated by SZ HW Test-曾小文 over 2 years ago

  • Status changed from VERIFIED to CLOSED

#11 Updated by CD FW-王伟 over 2 years ago

Gerrit Merge Information：
ID Project Branch Uploader
152609 Pre_figure/mcu Pre_figure_turbox-c2130c-la1.1-vendor-dev
BSP:MCU: MCU code buring up, storage, and feature integration
This commit protects the following functions:
1. Buring up of MCU code
2. Solve the power-on and power-on sequence bug
3. Increase the voltage protection function
4. MCU firmware upgrade function
TC-RID: 1201-0102701
TC-RID: 1201-0102703
TC-RID: 1201-0102704
IssueID: TS-R-BUG-111416
IssueID: TS-R-BUG-111734
IssueID: TS-R-BUG-111732
IssueID: TS-R-BUG-112002
IssueID: TS-R-DF-111421
IssueID: TS-R-DF-112099
IssueID: TS-R-DF-110660
IssueID: TS-R-DF-110663
IssueID: TS-R-DF-110664
Change-Id: Iacb3bbd40b9278405f21f5d34d741dfe08c3c4ff

#12 Updated by CD FW-王伟 over 2 years ago

Gerrit Merge Information：
ID Project Branch Uploader
152787 general/vendor/tc/mcu Pre_figure_turbox-c2130c-la1.1-vendor-dev
BSP: MCU: Add firmware for MCU programming and upgrade
The firmware version information is V0.0.1, which is the initial version. Implementation function:
1. Increase the power-on sequence
2. Increase the voltage protection function
3. Add version information
TC-RID: 1201-0102701
TC-RID: 1201-0102703
TC-RID: 1201-0102704
IssueID: TS-R-BUG-111416
IssueID: TS-R-BUG-111734
IssueID: TS-R-BUG-111732
IssueID: TS-R-BUG-112002
IssueID: TS-R-DF-111421
IssueID: TS-R-DF-112099
IssueID: TS-R-DF-110660
IssueID: TS-R-DF-110663
IssueID: TS-R-DF-110664
Change-Id: I047b1483f36d87a7a080b1470eb836cbc620a06e

#13 Updated by CD FW-王伟 over 2 years ago

Gerrit Merge Information：
ID Project Branch Uploader
154928 Pre_figure/mcu Pre_figure_turbox-c2130c-la1.1-vendor-dev
BSP:MCU: Functional integration version of the MCU
This version contains the following functions:
1.Improve the overvoltage protection function and increase the
over-voltage protection communication with the MMU;
2.Improve the function of power-on and power-up sequence, and
fix the problem that the boot screen is not displayed;
3.increase the can communication through, currently only open
the can's transceiver, there is no integration of other can's functions.
TC-RID: 1201-0102701
TC-RID: 1201-0102703
TC-RID: 1201-0102704
IssueID: TS-R-BUG-111416
IssueID: TS-R-BUG-111734
IssueID: TS-R-BUG-111732
IssueID: TS-R-BUG-112002
IssueID: TS-R-DF-111421
IssueID: TS-R-DF-112099
IssueID: TS-R-DF-110660
IssueID: TS-R-DF-110663
IssueID: TS-R-DF-110664
Change-Id: I0c7022c0c6e09e54f1b390deb1fb0df27ece4a38
