开发 Dev #114628
开发 Dev #110122: 【MK】管理总票
开发 Dev #110125: 【MK】【BSP】管理总票
开发 Dev #110654: 【MK】【005】【LCD】主任务
【MK】【005】【LCD】【TC-RID: 1201-0100501】Display DTC 状态检测
| Status: | 完成 Closed | Start date: | 2022-12-16 | |
|---|---|---|---|---|
| Priority: | Normal | Due date: | ||
| Assignee: | CD BSP-杜磊 | % Done: | 100% | |
| Category: | BSP | |||
| Target version: | - |
Description
增加I2C检测Display相关功能
开发步骤
1.在LOG中添加相关日志打印
2.确认上传到云端方案，提供相应接口
History
#1 Updated by CD BSP-余霄 over 2 years ago
目前驱动中已将状态检测添加到心跳包中
code：
https://dev.thundercomm.com/gerrit/c/general/kernel/msm-4.19/+/169137
新增心跳包获取display状态相关寄存器，并打印到LOG中
dmesg | grep DTC_Display,DTC_TP
打印如下:
DTC_Display:FSE_DisplayScreen_St=XX
DTC_Display:FSE_BacklightSw_St=XX
DTC_Display:FSE_BacklightGradual_St=XX
DTC_Display:FSE_BrightnessLim_St=XX
DTC_Display:FSE_Backlight_Val=XX
DTC_Display:FSE_ScreenTemp_Val=XX
DTC_Display:FSE_BatteryVol_Val=XX
DTC_Display:FSE_Lock_Fault_Rsp=XX
#2 Updated by CD BSP-余霄 over 2 years ago
- Assignee set to CD BSP-余霄
#3 Updated by CD BSP-杜磊 over 2 years ago
- Subject changed from 【MK】【005】【LCD】【TC-RID: 1201-0100501】Display状态检测 to 【MK】【005】【LCD】【TC-RID: 1201-0100501】Display DTC 状态检测
#4 Updated by CD BSP-杜磊 over 2 years ago
- Assignee changed from CD BSP-余霄 to CD BSP-杜磊
- % Done changed from 0 to 70
#5 Updated by IoT scm over 2 years ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 179318 | general/kernel/msm-4.19 | Pre_figure_turbox-c2130c-la1.1-vendor-dev | xiao.yu@thundersoft.com |
| BSP:Display: VC1 display/TP DTC Diagnostics VC1 Display/TP DTC Diagnostics TC-RID: 1201-0100501 IssueID: TS-R-DF-114628 Change-Id: Icc2e604e336985f1b43f4cac761bab1ee8d53251 |
|||
#6 Updated by CD BSP-杜磊 over 2 years ago
- Status changed from 进行中 In Progress to 解决 Resolved
- % Done changed from 70 to 100
#7 Updated by CD BSP-杜磊 over 2 years ago
- Category set to BSP
#8 Updated by IoT scm about 2 years ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 194495 | general/kernel/msm-4.19 | Pre_figure_turbox-c2130c-la1.1-vendor-ftm_v0090 | dulei0503@thundersoft.com |
| BSP:Display: Optimize VC1 lcd DTC diagnosis When lcd power-down or data cable disconnect, stop dtc diagnosis checking workqueue. Avoid outputting a large number of i2c error logs. TC-RID: 1201-0100501 IssueID: TS-R-DF-114628 Change-Id: I2aee473cdfec8124bf45a43fe139e9593a49ce8d |
|||
#9 Updated by IoT scm about 2 years ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 194652 | general/kernel/msm-4.19 | Pre_figure_turbox-c2130c-la1.1-vendor-ftm_v0090 | dulei0503@thundersoft.com |
| BSP:Display: Optimize VC1 lcd DTC diagnosis2 When lcd power-down or data cable disconnect, stop dtc diagnosis checking workqueue. Avoid outputting a large number of i2c error logs. TC-RID: 1201-0100501 IssueID: TS-R-DF-114628 Change-Id: I2fdf4c21ac6b8ff798d0351bf1b287c27316d59d |
|||
#10 Updated by IoT scm about 2 years ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 197361 | general/kernel/msm-4.19 | Pre_figure_turbox-c2130c-la1.1-vendor-ftm_v0095 | dulei0503@thundersoft.com |
| BSP:Display: Optimize VC1 lcd DTC diagnosis When lcd power-down or data cable disconnect, stop dtc diagnosis checking workqueue. Avoid outputting a large number of i2c error logs. TC-RID: 1201-0100501 IssueID: TS-R-DF-114628 Change-Id: I2aee473cdfec8124bf45a43fe139e9593a49ce8d |
|||
#11 Updated by IoT scm about 2 years ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 194479 | general/kernel/msm-4.19 | Pre_figure_turbox-c2130c-la1.1-vendor-dev | dulei0503@thundersoft.com |
| BSP:Display: Optimize VC1 lcd DTC diagnosis and driver init 1.Adjust max96755 driver initialization process. 2.When lcd power-down or data cable disconnect, stop dtc diagnosis checking workqueue. Avoid outputting a large number of i2c error logs. TC-RID: 1201-0100501 IssueID: TS-R-DF-114628 Change-Id: I2aee473cdfec8124bf45a43fe139e9593a49ce8d |
|||
#12 Updated by CD BSP-杜磊 about 2 years ago
- Status changed from 解决 Resolved to 完成 Closed
#13 Updated by IoT scm about 2 years ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 210929 | general/kernel/msm-4.19 | Pre_figure_turbox-c2130c-la1.1-vendor-dev | xiao.yu@thundersoft.com |
| BSP:Display: Fix some black screen issues 1.Fix some black screen issues 2.Add reinforcement log TC-RID: 1201-0100501 IssueID: TS-R-DF-114628, IOVDEV-35971 Change-Id: I7c0ee7ad64fcb2d6fad75427da46e56ed3f07dd6 |
|||
#14 Updated by IoT scm about 2 years ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 211630 | general/kernel/msm-4.19 | Pre_figure_turbox-c2130c-la1.1-vendor-release_sorp | wangxl0510@thundersoft.com |
| BSP:Display: Fix some black screen issues 1.Fix some black screen issues 2.Add reinforcement log TC-RID: 1201-0100501 IssueID: TS-R-DF-114628, IOVDEV-35971 Change-Id: I7c0ee7ad64fcb2d6fad75427da46e56ed3f07dd6 (cherry picked from commit 2ef28a8dab6d63a14bb75d72365ec99c90abb427) |
|||
#15 Updated by IoT scm almost 2 years ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 212169 | general/kernel/msm-4.19 | Pre_figure_turbox-c2130c-la1.1-vendor-dev | xiao.yu@thundersoft.com |
| BSP:Display: Fix the problem of false triggering of DTC 1.Fix the problem of false triggering of DTC 2.Add video register check stage TC-RID: 1201-0100501 IssueID: TS-R-DF-114628, IOVDEV-35971 Change-Id: I00c76d1059c05ed6e39b1691e949a35a6d34ca85 |
|||
#16 Updated by IoT scm almost 2 years ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 212458 | general/kernel/msm-4.19 | Pre_figure_turbox-c2130c-la1.1-vendor-release_sorp | wangxl0510@thundersoft.com |
| BSP:Display: Fix the problem of false triggering of DTC 1.Fix the problem of false triggering of DTC 2.Add video register check stage TC-RID: 1201-0100501 IssueID: TS-R-DF-114628, IOVDEV-35971 Change-Id: I00c76d1059c05ed6e39b1691e949a35a6d34ca85 (cherry picked from commit 893335c26bc6c5a0400b33ce172fd22dbffd1f7b) |
|||
#17 Updated by IoT scm almost 2 years ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 212967 | general/boot_images | Pre_figure_turbox-c2130c-la1.1-vendor-release_sorp | wangxl0510@thundersoft.com |
| BSP:Display: Modify the video detection solution(1/2) Detect video status information through the register TC-RID: 1201-0100501 IssueID: TS-R-DF-114628, IOVDEV-35971 Change-Id: Idb544d81950019b26e481aaa742f20ce5fab765f |
|||
#18 Updated by IoT scm almost 2 years ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 212968 | general/kernel/msm-4.19 | Pre_figure_turbox-c2130c-la1.1-vendor-release_sorp | wangxl0510@thundersoft.com |
| BSP:Display: Modify the video detection solution(2/2) 1.Detect video status information through the register 2.Fix the TP restart and cannot touch the problem 3.Fix the abnormal problem of CONFIG_CRC node value TC-RID: 1201-0100501 IssueID: TS-R-DF-114628, IOVDEV-35971 Change-Id: I9140683dfecd120450f8bdd1e5f4885860033783 |
|||
#19 Updated by IoT scm almost 2 years ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 212656 | general/kernel/msm-4.19 | Pre_figure_turbox-c2130c-la1.1-vendor-dev | xiao.yu@thundersoft.com |
| BSP:Display: Modify the video detection solution(2/2) 1.Detect video status information through the register 2.Fix the TP restart and cannot touch the problem 3.Fix the abnormal problem of CONFIG_CRC node value TC-RID: 1201-0100501 IssueID: TS-R-DF-114628, IOVDEV-35971 Change-Id: I9140683dfecd120450f8bdd1e5f4885860033783 |
|||
#20 Updated by IoT scm almost 2 years ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 212668 | general/boot_images | Pre_figure_turbox-c2130c-la1.1-vendor-dev | xiao.yu@thundersoft.com |
| BSP:Display: Modify the video detection solution Detect video status information through the register TC-RID: 1201-0100501 IssueID: TS-R-DF-114628, IOVDEV-35971 Change-Id: Idb544d81950019b26e481aaa742f20ce5fab765f |
|||
#21 Updated by IoT scm almost 2 years ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 213100 | general/kernel/msm-4.19 | Pre_figure_turbox-c2130c-la1.1-vendor-release_sorp | wangxl0510@thundersoft.com |
| BSP:Display: Modify the video detection solution(3/2) 1.Detect video status information through the register 2.Fix the TP restart and cannot touch the problem 3.Fix the abnormal problem of CONFIG_CRC node value TC-RID: 1201-0100501 IssueID: TS-R-DF-114628, IOVDEV-35971 Change-Id: Ib887b30a89ae912915758f98339221a05164f4ec |
|||
#22 Updated by IoT scm almost 2 years ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 302325 | general/kernel/msm-4.19 | Pre_figure_turbox-c2130c-la1.1-vendor-dev | xiao.yu@thundersoft.com |
| BSP:Display: Add vc1 heartbeart Add vc1 heartbeart TC-RID: 1201-0100501 IssueID: TS-R-DF-114628 Change-Id: Iebfc05f4d92e6498fbdbb8158726972975702aa3 |
|||
#23 Updated by IoT scm almost 2 years ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 304164 | general/kernel/msm-4.19 | Pre_figure_turbox-c2130c-la1.1-vendor-release_sorp | wangxl0510@thundersoft.com |
| BSP:Display: Add vc1 heartbeart Add vc1 heartbeart TC-RID: 1201-0100501 IssueID: TS-R-DF-114628 Change-Id: Iebfc05f4d92e6498fbdbb8158726972975702aa3 (cherry picked from commit 69ff4e74b1f6ece939969332d892a91edcf765c5) |
|||
#24 Updated by IoT scm over 1 year ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 310893 | general/kernel/msm-4.19 | Pre_figure_turbox-c2130c-la1.1-vendor-dev | xiao.yu@thundersoft.com |
| BSP:Display: VX1 Add video check Vx1 add video check TC-RID: 1201-0100501 IssueID: TS-R-DF-114628, IOVDEV-42488 Change-Id: I8e69512df9fd30502480a8d07e59691f715949e5 |
|||
#25 Updated by IoT scm over 1 year ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 323350 | general/kernel/msm-4.19 | Pre_figure_turbox-c2130c-la1.1-vendor-release_sorp_mce | wangxl0510@thundersoft.com |
| BSP:Display: VX1 Add video check Vx1 add video check TC-RID: 1201-0100501 IssueID: TS-R-DF-114628, IOVDEV-42488 Change-Id: I8e69512df9fd30502480a8d07e59691f715949e5 (cherry picked from commit 4d1164fb79f80d5ead2a1688377b7283295d623d) |
|||
#26 Updated by IoT scm over 1 year ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 326548 | general/kernel/msm-4.19 | Pre_figure_turbox-c2130c-la1.1-vendor-release_sorp | wangxl0510@thundersoft.com |
| BSP-Display: Add backlight recheck when panel off TC-RID: 1201-0100501 IssueID: TS-R-DF-114628, FIR-809 Change-Id: Ia44ed5bb50a9464fb5c82b2199661b49ed31faa0 |
|||
#27 Updated by IoT scm over 1 year ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 326549 | general/kernel/msm-4.19 | Pre_figure_turbox-c2130c-la1.1-vendor-release_sorp_mce | wangxl0510@thundersoft.com |
| BSP-Display: Add backlight recheck when panel off TC-RID: 1201-0100501 IssueID: TS-R-DF-114628, FIR-809 Change-Id: Ia44ed5bb50a9464fb5c82b2199661b49ed31faa0 |
|||
