Bug #116921
测试 Test-IT #111062: V3.0功能测试
测试 Test-IT #111069: AF-V3.0--Launcher/SystemUI-小窗模式入口
【AF】【EVT】【小窗模式】先全屏进入图片的编辑页面，再切换至小窗模式，被编辑的图片显示不完整
| Status: | CLOSED | Start date: | 2023-03-13 | |
|---|---|---|---|---|
| Priority: | Normal | Due date: | ||
| Assignee: | CD TEST-方永红 | % Done: | 100% | |
| Category: | 窗口定制 | |||
| Target version: | - | |||
| Need_Info: | -- | Found Version: | FlatBuild_HH_MCE_FSE.M.D.user.01.00.C101.202303110019 | |
| Resolution: | FIXED | Degrated: | -- | |
| Severity: | Normal | Verified Version: | FlatBuild_HH_MCE_FSE.M.R.user.01.00.0082.C101(X101) | |
| Reproducibility: | Every time | Fixed Version: | ||
| Test Type: | ST | Root cause: | 从Recent里面启动的时候会保留之前的配置,所有也会使用横屏的配置,导致在小窗情况下显示异常 |
Description
【前提条件】
1、设备已开机
【测试步骤】
1、打开图库
2、选择一张图片进行编辑页面
3、进入任务管理器
4、点击图库卡片的小窗按钮
5、查看页面显示
【预期结果】
5、页面显示正常
【实际结果】
5、被编辑的图片显示不完整
History
#1 Updated by CD FW-鲁凯峰 over 2 years ago
- Category changed from CD-FW to 窗口定制
#2 Updated by IoT scm over 2 years ago
Gerrit Merge Information：
| ID | Project | Branch | Uploader |
| 187231 | general/platform/packages/apps/Gallery2 | Pre_figure_turbox-c2130c-la1.1-qssi12-dev | lukf0916@thundersoft.com |
| FW:Gallery2: update filter show layout when multi mode changed force to use port layout in freeform mode TC-RID: 1201-0300701 IssueID: TS-R-BUG-116921 Change-Id: I5d70b5e60026ccfe735e0cdbd10bf999a14cf8f8 |
|||
#3 Updated by CD FW-鲁凯峰 over 2 years ago
- Status changed from New to RESOLVED
- Assignee changed from CD FW-鲁凯峰 to CD TEST-方永红
- Resolution changed from -- to FIXED
- Root cause set to 从Recent里面启动的时候会保留之前的配置,所有也会使用横屏的配置,导致在小窗情况下显示异常
■ Current conclusion
问题已经解决
■ My analysis
从Recent里面启动的时候会保留之前的配置,所有也会使用横屏的配置,导致在小窗情况下显示异常
修改方法是在小窗模式下强制使用竖屏的布局
■ Submit URL
http://10.0.232.3:3307/gerrit/c/general/platform/packages/apps/Gallery2/+/187231
#4 Updated by CD TEST-方永红 over 2 years ago
- Status changed from RESOLVED to VERIFIED
- % Done changed from 0 to 100
- Verified Version set to FlatBuild_HH_MCE_FSE.M.R.user.01.00.0082.C101(X101)
3.14
验证通过
#5 Updated by CD TEST-方永红 over 2 years ago
- Status changed from VERIFIED to CLOSED
