Bug #118197

【IOVDEV-29794】【内部】【VC1】【0095】【台架】【EE环境】【副屏】副屏屏幕和屏保之间来回闪动

Added by CDTS_Test 吴诗雨 about 2 years ago. Updated about 2 years ago.

Status:

CLOSED

Start date:

2023-05-23

Priority:

Normal

Due date:

Assignee:

CDTS_Test 吴诗雨

% Done:

10%

Category:

CD-APP

Target version:

Need_Info:

Found Version:

【中控版本号】：03.02.0082.c101

【副屏版本号】：01.00.0095.c103

Resolution:

Degrated:

Severity:

Normal

Verified Version:

Reproducibility:

Every time

Fixed Version:

Test Type:

Root cause:

Description

【环境信息】EE环境
【问题出现时间】：20230522 09：51
【前提条件】：副屏上电
【操作步骤】

1.副屏正常操作
【实际结果】
1.副屏主界面和屏保界面来回切换
【期望结果】
1.副屏正常保持不动

【备注】：

第136次开机

偶现问题，目前第一次，后面没有复现出来

日志、视频地址：https://ofs.human-horizons.com/#/download/index/5Ua2I8YExhg%3D

中控VIN号：HRYTTESTVINMGM817

【中控版本号】：03.02.0082.c101

【副屏版本号】：01.00.0095.c103


History

#1 Updated by CDTS_Test 吴诗雨 about 2 years ago

由于只出现了一次，没有视频

#2 Updated by CDTS_Test 吴诗雨 about 2 years ago

ftp://cdiot@192.168.87.46/Pre_figure/Test_Log/Bug_118197

#3 Updated by CD APP-王营 about 2 years ago

Status changed from New to NEED_INFO
Assignee changed from CD APP-王营 to CDTS_Test 吴诗雨
% Done changed from 0 to 10

【当前状态】
1、闪动的原因是副屏正常响应了中控的指令

【分析】
1、根据log分析可知，在问题发生时间点09：51：29，在1秒内中控向副屏发送了5次启动屏保的指令，log如下：
05-22 09:51:29.045 2216 5973 D RemoteControlService: After desEncrypt json is [{"value":"screensaver","source":1,"type":"screensaver","token":"58GyO9oGYVbHQMR"}]
05-22 09:51:29.549 2216 5980 D RemoteControlService: After desEncrypt json is [{"value":"screensaver","source":1,"type":"screensaver","token":"58GyO9oGYVbHQMR"}]
05-22 09:51:29.562 2216 5982 D RemoteControlService: After desEncrypt json is [{"value":"screensaver","source":1,"type":"screensaver","token":"58GyO9oGYVbHQMR"}]
05-22 09:51:29.712 2216 5990 D RemoteControlService: After desEncrypt json is [{"value":"screensaver","source":1,"type":"screensaver","token":"58GyO9oGYVbHQMR"}]
05-22 09:51:29.879 2216 5994 D RemoteControlService: After desEncrypt json is [{"value":"screensaver","source":1,"type":"screensaver","token":"58GyO9oGYVbHQMR"}]
05-22 09:51:30.047 2216 5999 D RemoteControlService: After desEncrypt json is [{"value":"screensaver","source":1,"type":"screensaver","token":"58GyO9oGYVbHQMR"}]

同时在发此过程中还发送了切换屏保状态的指令，由此可知，副屏正常响应了中控传递的状态，但是中控为什么频繁的发送启动和关闭屏保的指令需要中控调查。

【下一步】
1、测试确认当时的测试手法，是否有频繁发送启动屏保和退出屏保的指令？
2、中控调查频繁发送指令的原因。
